Hose (EPDM, etc.)
Components
Click image to enlarge
Details
The IMK-CLAMP02 is an annealed SUS304 crimp sleeve designed for secure assembly of EPDM hoses with UQD02-size quick connectors.
Its precision-machined construction supports consistent crimping and secure hose retention while helping reduce the risk of separation and leakage.
Key Specifications
- Outside diameter: Ø16.5 ±0.10 mm
- Groove root diameter: Ø14.8 ±0.10 mm
- Inside diameter: Ø13.8 +0.10/0 mm
- Overall length: 15 ±0.20 mm
- Groove angle: 90° ±1°
- Chamfer: C0.3 ±0.10
- Material: Annealed SUS304
Features
- Designed for EPDM hose assemblies
- Suitable for UQD02-size quick connectors
- Corrosion-resistant SUS304 construction
- Consistent crimping and secure hose retention
- Suitable for hose-kit assembly and maintenance
- Custom production available
Hose dimensions, connector geometry and crimping conditions must be verified before installation.
