HOSE CLAMP SUS304

이미지를 클릭하면 크게 볼 수 있습니다

IMK-EPDM HOSE CLAMP

HOSE CLAMP SUS304

주용도: Black EPDM HOSE CLAMP Stainless 304

문의하기 데이터시트 PDF

상세내용

Part No.	Outside Diameter	Groove Root Diameter	Inside Diameter	Length	Groove Angle	Chamfer	Material	Raw Material Size
IMK-CLAMP02	Ø15 ±0.10 mm	Ø13.3 ±0.10 mm	Ø12.3 +0.10 / 0 mm	15 ±0.20 mm	90° ±1°	C0.3 ±0.1	SUS304 Annealed	Ø16 mm
IMK-CLAMP04	Ø19 ±0.10 mm	Ø17.3 ±0.10 mm	Ø16.3 +0.10 / 0 mm	20 ±0.20 mm	90° ±1°	C0.3 ±0.1	SUS304 Annealed	Ø20 mm
IMK-CLAMP06	Ø25 ±0.10 mm	Ø23.3 ±0.10 mm	Ø22.3 +0.10 / 0 mm	22 ±0.20 mm	90° ±1°	C0.3 ±0.1	SUS304 Annealed	Ø25 mm
IMK-CLAMP08	Ø28.2 ±0.10 mm	Ø26.5 ±0.10 mm	Ø25.5 +0.10 / 0 mm	31 ±0.20 mm	90° ±1°	C0.3 ±0.1	SUS304 Annealed	Ø30 m
